Seagull Models Ultimate - Interplane Strut Installation; Installing Aileron Linkage (Upper-Lower Main Wing)

www.seagullmodels.com
23
2 sets.
Parts requirement. See pictures below:
INSTALLING THE AILERON LINKAGE
(UPPER-LOWER MAIN WING).
Place on strut into position. Make sure the
curves on the strut follow the airfoil of the wings.
INTERPLANE STRUT INSTALLATION.
M2 lock nut.
Snap keeper.
M2 clevis.
1.8x300mm.
6
5
B
5
D
D
6
B
7
8
