ZERO. Instruction Manual.
10
Switch.
Trim and cut.
150mm.
MOUNTING THE ENGINE.
 1) Position the engine with the drive washer
(150mm) forward of the firewall as shown.
THROTTLE SERVO ARM INSTALLATION.
Install adjustable servo connector in the servo
arm as same as picture below:
Adjustable Servo
connector.
Servo arm.
Loctite secure.
1 PCS.
Throttle servo arm.
Elevator servo arm.
Rudder servo arm.
3/ 32” Hole.
INSTALLING THE SWITCH.
Install the switch into the precut hole in the
side, in the fuselage.
SERVO GEAR INSTALLATION.
Servo for retractable only.
Metal connector.
Servo arm.
25mm.
Throttle servo arm.
Elevator servo arm.
Rudder servo arm.
Stearing servo arm.
