MiniWarden Manual 530-487-5007 12
DEFAULT READINGS SCREEN
The Default Readings Screen is displayed after power up and when a
button isn’t pressed for a period of time. It is the most critical screen as it
will display the current pH & ORP sensor readings, ow status, relay
status, alarm status and various symbols that are dened below. Menus
within MiniWarden are accessed through the Default Readings Screen .
ORP pH Tf Flow
681 7.7 75 ON a
Relay ↑↓
Default Readings Screen
m
v
Please review denitions of all Row & Column information and symbols below.
Row 1 (Column Header): The rst row is a column header and denes what you nd below that particular
column header. Example above: The “pH” Column Header on the rst row means that the current pH
readings is 7.7. When the MiniWarden is turned on a number will display on this line to the right which is a
delay before the relays will operate, the turn on delay gives time for accurate reading prior to controlling the
relays.
Row 2 (Current Measurements): The current real time measurements and alarm status. Example above:
ORP=681, pH=7.7, Temperature (Tf) = 75 degrees Fahrenheit, Flow = ON. The “a” on the far right
indicates that the alarm is on.
Row 3 (Flow switch 2): The current status of Flow Switch 2 (advanced mode).
Row 4 (Relay Status): Row 4 displays the current status of both relays in the following order with symbols
that are dened below:
❑ Rly: ORP pH1
❑ _ : An underline indicates the relay is OFF and not in an active feed cycle.
❑ ↑ : An Up arrow indicates the relay is ON and in an active feed cycle.
❑ ↓ : A Down arrow indicates the relay is OFF and in the OFF part of an active cycle.
❑ o : An "o" indicates the relay has reached the on time limit (overfeed limit) for the day and will not turn
on again until the overfeed limit clears automatically each night at midnight or when PoolWarden’s
power is cycled (advanced mode).
s : An "s" indicates the relay has reached the setpoint overfeed limit and will not turn on again until
the setpoint is achieved by other means (manually adding the required chemicals). The only other way
to clear this is to cycle power. NOTE: The setpoint overfeed will not clear when the Clear Overfeed
menu item is selected in the service menu or at midnight like the daily overfeed.
❑ p In the ORP position indicates pH lockout and is on and sanitizer feed is disabled..
Other Symbols Dened:
❑ The letter “a” on the right will display when the Pool alarm is on.
❑ “p” In the last 4 characters of the display screen, indicates a user PIN code has been entered, this will
clear when it is sent to the server (advanced mode).
❑ “N” or “c” is displayed in the lower right indicates communication status with remote networks
(advanced mode).
The LOCK symbol in the lower right indicates security is enabled.
Selecting Simple/Advanced Mode
To change modes, press the Back button to access the Main Menu. While in
the Main Menu press the Right and Left arrow at the same time. WARNING:
All settings will be reset to factory defaults. Press 9 to make the change, any
other button to exit without making any changes.
Operating Mode
Resets all defaults
Current Mode-Simple
9=Change to Advanced
Mode Selection
To Next Page
