MiniWarden Manual 530-487-5007 14
MiniWarden Simple Mode Menus
MiniWarden Simple Mode
When switching between simple and advanced mode all settings are reset to factory defaults. Some of the
features that are not supported in simple mode include:
1. Communication: Simple mode will not send data to the data server and the Ethernet module isn’t
supported.
2. TrueDPD: Simple mode will not interface with the TrueDPD free chlorine sensor.
3. Flow Switch 2: Is not used in simple mode.
4. Daily Overfeed: The 24 hour overfeed timers are not used in simple mode.
Simple Mode Features
1. Cycle time control, select either 30 or 60 seconds.
2. ORP and pH spread based control instead of a proportional percentage.
3. Setpoints easy to set from the main menu.
4. Alarm menu includes values for pH and ORP only.
5. Adjustable ORP and pH spread,including 0.
6. PH Support for acid or base.
7. PH Lockout on ORP control.
8. Adjustable setpoint overfeed from 1 to 6 hours.
Alarms
ORP High Alarm 800
ORP Low Alarm 600
pHHigh Alarm 8.0 PH
Low Alarm 7.0
Press
Back Key
Back
ORP pH Tf Flow
681 7.7 75 ON a
Relay ↑↓
Default Readings Screen
m
v
Options
ORP Spread: 0
PH Spread: 0.0
Feed Cycle: 60s
pH Control: Acid
pH Lockout: O
ORP FeedLMT:01:00:00
PH FeedLMT:03:00:00
Time: 12:36:17
Date: 03/27/15
Day : Friday
Password:0
ORP Set 700 Alarms
pH Set 7.5 Data
Calibrate Relay
Manual Feed Options
Main Menu
Handy Menu
Enter Password
Last 7 Days Data
Enter Measurements
Relay Information
Right Arrow
Active Alarms
Up Arrow
Startup Screen
To Next Page
