MiniWarden Manual 530-487-5007 29
❑ ↑+big: Pressing the Up Arrow will jump forward 30 rows of data. The up arrow also works in
conjunction with the #*10Big Jump above. If any number between 1 through 9 is pressed followed
by the up arrow then it will jump the data by a factor of 10 times that number.
❑ > +1: Pressing the Right Arrow will move forward one “1” data row at a time.
❑ < - 1: Pressing the Left Arrow will move backward one “1” data row at a time.
❑ ↓-big: Pressing the Down Arrow will jump forward 30 rows of data. The up arrow also works in
conjunction with the #*10Big Jump above. If any number between 1 through 9 is pressed followed
by the down arrow key then it will jump the data by a factor of 10 times that number.
 Interval 00:00:00: Set the data recording time interval. The default setting is 00:00:00 or disabled.
Simply press Enter to scroll through the following data recording intervals. Each interval will ll the
internal memory as shown below. Once the memory is full then the new data will overwrite the oldest
data rst.
❑ 00:00:00: Disabled, No Data Recording
❑ 00:01:00: Data will record in 1 minute intervals. Internal Memory will be full in 5.5 Days.
❑ 00:05:00: Data will record in 5 minute intervals. Internal Memory will be full in 5.5 Days.
❑ 00:15:00: Data will record in 15 minute intervals. Internal Memory will be full in 85 Days.
❑ 00:30:00: Data will record in 30 minute intervals. Internal Memory will be full in 170 Days.
❑ 01:00:00: Data will record in 1 hour intervals. Internal Memory will be full in 341 Days.
 Clear Data: Simply scroll down to “Clear Data” and press Enter and the internal memory will reset to
0/8192.
Used 0 / 8192: This shows how much internal memory is currently being used. If a number like
3150/8192 is seen in this screen, then that means 3150 rows of data have been recorded out of the
available 8192 rows. Press Enter to immediately record data. If there is a lower case “o” on the fourth
line then the data is in overow mode and any new recorded data is erasing the oldest recorded data.
System Menu
The System Menu is where many of the main operating system components
are turned on or o. Please review and set each item according to the
needs of MiniWarden and the client being served. To access the System
Menu press Back from the “Default Readings Screen” and scroll down the
Main Menu to System and press Enter.
 Time: The time clock in PoolWarden is based on 00:00:00 military time.
Simply press Enter and set the correct time and press Enter again to
save the new time.
 Date: Simply press Enter and set the correct date and press the Enter
key again to save the new date.
 Day: Press the Enter key to toggle through to the appropriate day of the
week and press the Back key to save the new day of the week.
 Units: Press Enter to toggle between the English or Metric System.
System
Time: 12:36:17
Date: 03/27/15
Day : Friday
Units: English
Daylight Savings No
Langlier pH +/-0.2
TrueDPD Free Cl OFF
TrueDPD Cycle:10 min
ORP Cal: Enabled
Service QuickJmp On
Display Type: LCD
Factory Defaults
 Daylight Savings: Press Enter to toggle between YES to enable daylight savings time or NO to
disable daylight savings. The default setting is set to YES which means that MiniWarden will
automatically adjust for daylight savings time each year.
 Langlier pH +/- 0.0: When the Langlier Index falls outside of the balanced range of -0.5 to +0.5, the pH
set-point within MiniWarden will be adjusted by this pre-set factor to help keep the Langlier Index within
the range of -0.5 to +0.5 (Balanced). To change the Langlier pH adjustment factor, simply press Enter
to toggle through +/- 0.0, +/- 0.1, +/- 0.2 or +/- 0.3. The set-point within MiniWarden will be adjusted by
this Langlier Index Adjustment Factor once the pH sensor reading has reached the existing set-point.
To view the Langlier Index simply press the Right Arrow twice from the “Default Readings Screen”. To
perform a quick view of the current set-points simply press the 9 button when at the “Default Readings
Screen”. Langlier is enabled after manual measurements have been entered in the “Handy Menu”.
