SeaSTAR i6800 - Control Head - Single Lever

A-2
© 2013 SeaStar Solutions i6800 Installation Supplement, Rev. C
A.2 Control Head – Single Lever
3" (76mm) DIA.
3 x 1/4" (6.35mm) DIA.
1.0"
(25.4mm)
1.0"
(25.4mm)
1.6"
(41mm)
If you must photocopy this mounting template for use, check ALL
measurements using a measuring device prior to using as a template.
NOTICE
✁
