Seat Ateca 2016 - Page 94

Emergencies
No. Consumers/Amps
12 Radio 20
14 Air conditioner fan 40
15 Steering column release 10
16 Connectivity box koppelantenne 7.5
17 Instrument panel 5
18 Rear camera 7.5
19 Kessy 7.5
21 4x4 Haldex Control Unit 15
22 Trailer 15
23 Right lights 40
24 Electric sunroof 30
25 Left door 30
26 Heated seats 30
28 Trailer 25
31 Left lights 40
32
Parking aid control unit 7.
5/10
33 Airbag 5
34
Reverse switch, clima sensor, electro-
chromic mirror
7.5
35
Diagnosis, headlight control unit,
headlight adjuster
10
No. Consumers/Amps
36 Front camera, Radar 5/10
38 Trailer 25
39 Right door 30
40 12V socket 20
42 Central locking 40
43 Interior light 30
44 Trailer 15
45 Electric driver's seat 15
47 Rear window wiper 15
49 Starter motor; clutch sensor 5
50 Electric rear lid 40
53 Heated rear window 30
Fuse arrangement in engine compartment
No. Consumers/Amps
1 ESP control unit 40
2 ESP control unit 40
3
Engine control unit (diesel/pet-
rol)
30/15
4 Engine sensors 5/10
5 Engine sensors 10
6 Brake light sensor 5
No. Consumers/Amps
7 Engine power supply 10
8 Lambda probe 10/15
9 Engine 5/20
10 Fuel pump control unit 15/20
11 PTC 40
12 PTC 40
13 Automatic gearbox control unit 15/30
14 Heated windscreen 40
15 Horn 15
17 Engine control unit 7.5
18 Terminal 30 (positive reference) 5
19 Front windscreen washer 30
20 Alarm horn 10
22 Engine control unit 5
23 Starter motor 30
24 PTC 40
31 Pressure pump 15
33 Gearbox pump 30
37 Parking heating 20
