The essentials
strap (Top Tether) and lower anchoring
points on the seat.
Weight group
Seating position
Front passenger seat
a)
Rear side seat Rear central seat
b)
airbag on airbag off
Group 0 to 10 kg X U
c)
U U
Group 0+ to 13 kg X U
c)
U U
Group I 9 to 18 kg X U
c)
U U
Group II 15 to 25 kg X UF
c)
UF UF
Group III 22 to 36 kg X UF
c)
UF UF
X: It is not compatible to install chairs in this configuration.
U: Suit
able f
or universal restraint systems for use in this weight group.
UF: Acceptable for front-facing universal-category child restraint systems approved for this mass group.
a)
Compliance with current national legislation and the manufacturer's instructions is required when using or installing child seats.
b)
For semi-universal chairs where the securing system is the car safety belt and the support bracket, do not use them in the centre rear seat.
c)
Seats without height adjustment shoul
d be pl
aced in their r
earmost position. Seats with height adjustment should be placed in their rearmost and highest position.
›››
in Safety instructions on
page 83
Securing child seats with “ISOFIX” and Top Tether*
Child seats can be secured quickly, easily
and saf
ely on the r
ear out
er seats with the
“ISOFIX” and Top Tether* system.
Two “ISOFIX” retaining rings are fitted on both
outermost rear seats. In some vehicles, the
rings are secured to the seat frame and, in
others, they are secured to the rear floor. The
“ISOFIX” rings are located between the rear
seat backrest and the seat cushioning
››› Fig. 39. The Top Tether* rings are located
on the rear part of the backrests of the rear
28
