Undo the opening limit
er ›
›
› Fig. 106
A
in
tw
o st
eps: first, unl
ock the limiter by pulling
back on it (arrow
1
) and then move it gently
t
o the right (arr
o
w
2
). Remove the guide
when the co
v
er is in the normal opening posi-
tion (30°).
●
Fr
ee the side pivots
B
to release the cover
t
o its second opening position (60°).
F
oll
ow the same procedure in reverse order
to return the glove compartment to its normal
position.
CAUTION
●
Always car
efully remove the fuse box
covers and refit them correctly to avoid
problems with your vehicle.
●
Protect the fuse boxes when open to
avoid the entry of dust or humidity. Dirt and
humidity inside fuse boxes can cause dam-
age to the electrical system.
Engine compartment fuses
Fig. 107
In the engine compartment: lid of the
fuse bo
x.
To open the engine compartment fuse box
●
Open the bonnet ›
›
›
page 348.
●
Press the locking tabs to release the fuse
box cover ››› Fig. 107.
●
Then lift the cover out.
●
To fit the cover, place it on the fuse box.
Push the locking tabs down until they click
audibly into place.
Fuse placement
Read the additional information carefully
›
›
›
page 52
Only replace fuses with a fuse of the same
amperage (same colour and markings) and
size.
Fuses in the vehicle interior
No. Consumers/Amps
1 Adblue (SCR) 20
5 Gateway 5
6 Automatic gearbox lever 5
7
Air conditioning and heating
control panel, back windo
w
heating, auxiliary heating.
10
8
Diagnosis, handbrake switch,
light switch, r
everse light, interi-
or lighting, driving mode, lit-up
door sill
10
9 Steering column 5
10 Radio display 7.5
11 Left lights 40
12 Radio 20
14 Air conditioner fan 40
15 Steering column release 10
16 Connectivity Box 7.5
17 Instrument panel, OCU 7.5
18 Rear camera 7.5
19 Kessy 7.5
20 SCR, engine relay, 1.5 10/15
21 4x4 Haldex Control Unit 15
»
