Trailer towing 207
Safety First Operating Instructions Practical Tips Technical Specifications
Fitting the ball joint (step 1)
– Remove the cover piece ⇒ fig. 163 on the mounting fixture
below the bumper as far as it will go. The cover piece is held
automatically in the open position.
– Make sure the mounting fixture is clean. If not, clean it ⇒ .
Cont ⇒ page 207, “Fitting the ball joint (step 2)”.
WARNING
It is important to keep the mounting fixture clean. Otherwise the ball joint
may fail to engage safely and securely. This could lead to an accident.
Fitting the ball joint (step 2)
Fig. 163 Rear bumper:
Open the cover piece
2
1
Fig. 164 Removable
towing bracket: Ball joint
Fig. 165 Removable
towing bracket: Ball joint
ExeoST_EN.book Seite 207 Freitag, 3. September 2010 11:41 11
