If and when288
– Fit the new bulb, pressing it into the bulb holder and turn it to the
right as far as it will go.
– Use a cloth to remove any fingerprints from the glass part of the
bulb.
– Check whether the new bulb is working.
– Re-install the bulb holder ⇒ page 288.
Position of the bulbs
Fitting the bulb holder
The bulb holder is easy to fit.
– Position the bulb holder on the tail light and align it so that it is
securely seated.
– Press the bulb holder into the tail light until it engages.
– Fit the cover back in the interior trim so that it engages.
– Put the screwdriver back into the tool kit.
– Make sure that all bulbs for the tail lights are working.
Side turn signals
– Press the turn signal to the left or to the right to remove the bulb.
– Remove the bulb holder from the turn signal.
– Remove the failed glass bulb and replace with a new bulb.
– Insert the bulb holder in the turn signal guide until it clicks into
place.
– First place the turn signal in the opening in the bodywork, fixing
the tabs ⇒ fig. 238, arrow .
– Insert the bulb as shown by the arrow ⇒ fig. 238.
Pos. ⇒ page 287,
fig. 236
Bulb function
A Reverse lights
B Rear fog light
Fig. 238 Side turn signal
A
1
A
2
