Trailer towing 211
Safety First Operating Instructions Practical Tips Technical Specifications
– Take hold of the ball joint and pull out the knob in direction .
– Keep hold of the knob and turn it as far as it will go in direction
.
– Release the knob. The spring mechanism will remain in the ready
position ⇒ .
– Pull the ball joint down out of the mounting fixture
⇒ page 210, fig. 171. The cover piece will cover the mounting
fixture automatically .
– Put away the ball joint attachment under the floor panel in the
luggage compartment.
– Move the socket back up to its original position.
WARNING
• To avoid injury, keep your hands away from the locking pin and the
release pin when releasing the locking mechanism.
• Make sure that the cover piece is properly engaged on the mounting
fixture on the vehicle. Otherwise the ball joint may fail to engage securely
if dirt accumulates in the mounting fixture.
A
B
1
2
