If and when266
Caution
Never “repair” damaged fuses and never replace them with fuses with a
higher rating. Failure to comply could result in fire. It could also cause
damage to other parts of the electrical system.
Note
If a newly replaced fuse blows again after a short time, the electrical system
must be checked by a qualified workshop as soon as possible.
Fuse assignment
This list shows the fuses which can be replaced relatively
easily by the owner.
No. Consumer Amps
1 Air conditioner 10
2 Footwell lamps 5
3 Heated washer jets 5
4 Radiator fan 5
5 Parking aid, automatic gearbox 10
6 Air conditioner (air purity sensor), pressure sensor 5
7
Electronic Stability Programme (ESP), brake light
switch, clutch pedal switch, steering angle sensor
10
8 Telephone 5
9 Vacant
10 Adaptive headlights right 5
11
Airbag and disconnection of the front passenger air-
bag
5
12 Diagnostic socket 10
13 Steering column unit 10
14 Brake lights 10
15 Instrument panel 10
16 Vacant
17 Tyre pressure control, rain/light sensor 10
18 Adaptive headlights left 5
19 Vacant
20 Vacant
21 Vacant
22 Driver door / front passenger door 15
23 Rear doors 15
24 Central electrics unit for convenience equipment 20
25 Heater blower 30
26 Rear window heater 30
27 Power socket for trailer (control unit) 30
28 Fuel pump, auxiliary pump for diesel 20
29 Vacant
30 Sliding/tilting sunroof 20
31
Diagnosis connection, automatic anti-dazzle interior
mirror, reverse light, automatic gearbox
15
32 Towing socket 15
No. Consumer Amps
