If and when286
Remove the bulb holder
The tailgate must be open to change the bulbs.
You can access the bulb holder for the inner tail lights via the inside
of the tailgate.
– Check which of the bulbs is defective.
– Take the screwdriver out of the vehicle's tool kit ⇒ page 254.
– Insert the screwdriver into the opening in the cover ⇒ fig. 234
and detach the cover .
– Press on the tabs ⇒ fig. 235 in the direction of the arrows
and remove the bulb holder by pulling in the direction of the
arrow .
– Change the bulbs ⇒ page 287 ⇒ page 287.
WARNING
If a bulb is replaced in a tail light assembly with LED, do not pull too hard
on the bulb holder to avoid damaging the wiring of the LED module.
Fig. 234 Remove the
cover of the tailgate trim
Fig. 235 Remove the bulb
holder
1
A
2
A
B
