Section 4 – elevator installation
step 1
Insert in the elevator the four hinges into their appropriate slots and verify the correct position and
alignment of the elevator with the stabilizer. Than carefully glue the hinges, with some drops of thin
CA, in the elevator only.
step 2
Insert carefully the elevator through the fuselage.
step 3
Insert the stabiliser into fuselage space and locate the elevator hinges into the stabiliser.
