6.5.3 Optional communication interface
USB communication interface
Install the intelligent monitoring software UPSilon2000 which is equipped with the UPS. Then it can
achieve the communication with monitoring device directly. When RS232 and USB are provided, only
one of them will be chosen and USB is preferred.
Intelligent slot
The following intelligent cards can be installed into the intelligent slot of the UPS: intelligent USB card,
intelligent SNMP card and intelligent dry contact card. Support the hot plug and play. Any card of
them can be used according to users’ requirements.
a) Intelligent USB card: Use the monitoring function of the USB interface system to monitor and
manage the power source of the UPS.
b) Intelligent SNMP card: When connecting to the internet by SNMP card, it communications with the
monitoring computer to monitor power source of the UPS from far end.
c) Intelligent dry contact card: Use the monitoring function of the dry contact interface system to
monitor and manage the power source of the UPS.
NOTE: Remove the cover before installing the optional accessories.
Intelligent Slot can be used together with RS232.
The operating instruction of the UPSilon2000 can be acquired from the CD.
As for the operating instructions of the intelligent USB card, SNMP card and dry contact card please
refer to the relative special instructions.
