Module Information
Y3802 MODULE AUDIO BLOCK DIAGRAM
CONFIGURATION LIMITATIONS
The Y3802 module can only be used in 12 or 16 channel Seeport 2 fra-
meworks. The module is positioned between the monitor and power mo-
dules.
3. MODULES
