5.5 Connector Information
5. TECHNICAL INFORMATION
Audio Connectors
All standard audio inputs and outputs are terminated on XLR connectors, wired as follows:
Pin1: Ground
Pin2: Hot (+phase)
Pin3: Cold (-phase)
Headphones Connectors
The mixer has two separate 1/4” stereo jack headphones connections. These are located un-
der the carrying handle in front of the master module. Level controls are located on the M3810
monitor module (phones 1 and phones 2). An additional headphones connector is also found
on the optional Y3802 module.
Signal Connectors
Remote start for all channels and master output faders together with two CUE signals are
available on 25-pin female D-connectors. The 8 channel mixer has one connector, the 12 and
16 channel mixers have two connectors. Pin-outs are given below. All outputs are in the form
of a bipolar solid state relay switch, capable of 100 mA.
REMOTE CONTROL CONNECTOR:
8 Ch. Mixer 12 Ch. Mixer 16 Ch. Mixer
Pin 1-14 ................................................................................. Ch.1
Pin 2-15 ................................................................................. Ch.2
Pin 3-16 ................................................................................. Ch.3
Pin 4-17 ................................................................................. Ch.4
Pin 5-18 .................................................. Ch.1 ...................... Ch.5
Pin 6-19 .................................................. Ch.2 ...................... Ch.6
Pin 7-20 .................................................. Ch.3 ...................... Ch.7
Pin 8-21 .................................................. Ch.4 ...................... Ch.8
REMOTE CONTROL / CUE CONNECTOR:
8 Ch. Mixer 12 Ch. Mixer 16 Ch. Mixer
Pin 1-14 ................ Ch.1 ......................... Ch.5 ...................... Ch.9
Pin 2-15 ................ Ch.2 ......................... Ch.6 ...................... Ch.10
Pin 3-16 ................ Ch.3 ......................... Ch.7 ...................... Ch.11
Pin 4-17 ................ Ch.4 ......................... Ch.8 ...................... Ch.12
Pin 5-18 ................ Ch.5 ......................... Ch.9 ...................... Ch.13
Pin 6-19 ................ Ch.6 ......................... Ch.10 .................... Ch.14
Pin 7-20 ................ Ch.7 ......................... Ch.11 .................... Ch.15
Pin 8-21 ................ Ch.8 ......................... Ch.12 .................... Ch.16
Pin 9-22 ................ A/B........................... A/B........................ A/B
Pin 10-23 .............. CUE 1 ...................... CUE 1 ................... CUE 1
Pin 11-24 .............. CUE 2 ...................... CUE 2 ................... CUE 2
