Smart Positioner

SP740 Series

7. PCB board Type - Option

Position transmitter(PTM) and HART communication can be easily mounted as added function.

There are four type PCB as followings.

< 표준 기판 + 리밋스위치형 > < 표준 기판 >

Fig 7-1 : Standard PCB board

Fig 7-2 : Standard PCB board + limit switch type

27/40

Types of PCB ( Option )

< 표준 기판 + Hart 기판형 > < 표준 기판 + 리밋스위치 + Hart 기판형 >

Hart 기판Hart 기판

HART board

Fig 7-3 : <Standard PCB board + HART PCB board type>

Fig 7-4 <Standard PCB board + limit switch + HART PCB

board type>
