50
www.seuservice.com
This test displays the following screen on the monitor.
B) OUTPUT TEST
OUTPUT TEST MENU
LAMP TEST
DRIVE BOARD TEST
-> EXIT TO SYSTEM TEST MODE
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
LAMP TEST
SC BUTTON LAMP OFF
TC BUTTON LAMP OFF
ABS BUTTON LAMP OFF
IBS BUTTON LAMP OFF
START BUTTON LAMP OFF
LEADER LAMP OFF
PRESS TEST BUTTON TO EXIT
• The OUTPUT TEST displays the following screen on the monitor.
a) LAMP TEST
b) DRIVE BOARD TEST
Selecting LAMP TEST displays the following screen on the monitor.
Upon entering the LAMP TEST, each lamp's display automatically changes to ON from OFF.
At this time, if each lamp lights up, operation is satisfactory. Press TEST Button to return to
GAME TEST MODE MENU screen.
a) LAMP TEST
To Next Page
