EXPLANATION OF TEST AND DATA DISPLAY
65
9
Use the JVS INPUT TEST to test the JVS input.
The hexadecimal input information from the JVS I/O board will be displayed in real time.
■JVSINPUTTESTScreen
NOTE: The screen display will vary depending on the I/O board that is connected.
The gure above is one example.
JVS TEST
INPUT TEST
NODE 1/*
SYSTEM 00 ROTARY 0 0000
PLAYER 1 0000 ROTARY 1 0000
PLAYER 2 0000 ROTARY 2 0000
COIN 1 0000 ROTARY 3 0000
COIN 2 0000 ROTARY 4 0000
ANALOG 0 0000 ROTARY 5 0000
ANALOG 1 0000 ROTARY 6 0000
ANALOG 2 0000 ROTARY 7 0000
ANALOG 3 0000
ANALOG 4 0000
ANALOG 5 0000
ANALOG 6 0000
ANALOG 7 0000
PRESS TEST BUTTON AND
SERVICE BUTTON TO EXIT
JVS INPUT TEST
The following information is displayed on this screen.
Press the SERVICE and TEST Buttons simultaneously to return to the JVS TEST screen.
SYSTEM System switch input data
PLAYER Player number and player switch input data
COIN Slot number and coin input data
ANALOG Channel number and analog input data
ROTARY Rotary number and rotary input data
