90
GRAPHICS DISPLAY
11
11-3 ADJUSTMENT METHOD
All adjustment values are set accurately at the time of shipping from the
factory. Do not readjust these values needlessly or apply adjustments not
specied in this manual. The display may not appear properly if the values
are incorrect.
CONTROL - ADJUSTMENT PROCEDURE
This sections explains basic control procedures for making adjustments using the buttons on
the 'Monitor Adjustment Board'
This Adjustment Board, and the Monitor Power Supply are located behind the Rear Door.
11-3 Fig. 01
Power Supply
LCD Driver Bd
42” LCD Panel
LCD Controller PCB
To Next Page
