PARTS LIST
117
18
1 TOPASSYLGJ （D-2/2）
ITEM NO. PART NO. DESCRIPTION NOTE
1 LGJ-1000UK ASSY MAIN CABINET
2 LGJ-1200UK ASSY SEAT CABINET
3 LGJ-1300UK ASSY DLP
4 LGJ-1400UK ASSY BILLBOARD BOX
5 LGJ-1450UK ASSY TOP BOARD
6 LGJ-0001UK DLP JOINT UPPER
7 LGJ-0002UK DLP JOINT SIDE
8 LGJ-0004UK MAT BRACKET L
9 LGJ-0005UK MAT BRACKET R
10 LGJ-0006UK REAR HARNESS COVER
11 LGJ-0007UK HARNESS COVER S
16 421-7988-91UK STICKER SERIAL NUMBER UK
20 LGJ-1007XUK SIDE CLOTH L
21 LGJ-1008XUK SIDE CLOTH R
22 LGJ-1454UK ENTRANCE TOP L
23 LGJ-1455UK ENTRANCE TOP R
28 LGJ-1002XUK CLOTH BRACKET
29 LGJ-1003UK CLOTH BRACKET AL
30 LGJ-1004UK CLOTH BRACKET AR
31 LGJ-1005UK CLOTH BRACKET BL
32 LGJ-1302XUK BRKT DLP CURTAIN
201 030-000620-WB HEX BLT W/FS BLK M6 × 20
202 000-F00616 M SCR FH M6 × 16
203 030-000620-WC HEX BLT W/FS CRM M6 × 20
204 000-P00416-W M SCR PH W/FS M4 × 16
205 000-T00408-0C M SCR TH CRM M4 × 8
206 000-T00430-0B M SCR TH BLK M4 × 30
207 030-000630-SB HEX BLT BLK W/S M6 × 30
208 000-T00416-0B M SCR TH BLK M4 × 16
209 068-652016-0B FLT WSHR BLK 6.5-20 × 1.6
401 420-6988UK OWNERS MANUAL LGJ DX ENG
402 420-6921-01 SERVICE MANUAL LBG ENG
406 600-6729-01 AC CABLE CONNECT TYPE 15A W/E
406 600-6619-02 AC CABLE CONNECT TYPE FOR UK
407 540-0006-01 WRENCH M4 TMP SCR
408 540-0007-01 WRENCH M5 TMP SCR
To Next Page
