Sega Let's Go Jungle User Manual

PARTS LIST
149
18
24 ACUNIT(LGJ-1330)
ITEM NO. PART NO. DESCRIPTION NOTE
1 HDF-0661UK BRKT AC HDF
2 LB1126-5-250 FUSE LABEL 5 AMP 250
3 LB1131 LABEL ON/OFF
101 EP1382 FILTER SCHFFNER FN682-10/06
102 EP1387 IEC INLET & SW
103 514-5078-5000 FUSE 5X20 CERAMMIC SB 5A
108 310-5029-D508 HEAT SHRINK SLEEVING
201 000-T00425-0B M4X25 MSCR TH BLK
202 000-P00312-W M3X12 MSCR PAN W/FS PAS
203 050-F00400 M4 NUT FLG SER PAS
301 ABX-600174UK WH AC BRKT
NO DRAWING AT TIME OF PRINT
