PRECAUTIONS WHEN MOVING THE MACHINE

Remove the front harness cover from the Main

Cabinet ceiling panel. Remove the six screws.

The screws have at & spring washers attached

to them.

FIG. 7-2e

FIG. 7-2f

Disconnect the two connectors in the box on the

Main Cabinet ceiling panel.

FIG. 7-2g

FRONT HARNESS COVER

M4x16, w/at & spring washers

SCREW (6), black

Disconnect the two connectors.
