( 4 ) INPUT TEST
Selecting the INPUT TEST on the test mode menu
screen causes the screen (on which each switch and
V. R. are tested) to be displayed. Press each switch.
If the display beside each switch indicates "ON," the
switch and wiring connections are satisfactory.
Check the display of each V.R. value. If the V. R. is
malfunctioning, refer to Sections 11 & 12.
( 5 ) OUTPUT TEST
In the output test mode, carry out lamp test to
ascertain that each lamp lights up satisfactorily.
( 3 ) SOUND TEST
In the test mode, selecting SOUND TEST causes
the screen (on which sound related BD and wiring
connections are tested) to be displayed.
Be sure to check if the sound is satisfactorily
emitted from each speaker and the sound volume is
appropriate.
Perform the above inspections also at the time of monthly inspection.
SOUND TEST
RIGHT SPEAKER OFF
LEFT SPEAKER OFF
EXIT
SELECT WITH SERVICE BUTTON
AND
PRESS TEST BUTTON
INPUT TEST
HANDLE BAR 0H
ROLL 0H
THROTTLE LEVER FFH
PITCH 0H
START OFF
VIEW OFF
SAFETY SENSOR OFF
SERVICE OFF
TEST OFF
PRESS TEST AND SERVICE BUTTON TO EXIT
OUTPUT TEST
> START LAMP OFF
VIEW LAMP OFF
EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
