WIRING TEST
Selecting WIRING TEST allows the communication between GAME BD and DRIVE BD to be
checked automatically. If the communication is satisfactorily conducted, "OK" is displayed and if any
irregularity is found, "ERROR" will be displayed.
• After nishing the test, if the above Figure is displayed, it is satisfactory.
• After nishing the test, press the TEST Button to return to the Game Test Menu screen.
FIG. 9. 3 g WIRING TEST Screen
WIRING TEST
ok : ( f 0 ——> 1 1 1 1 1 1 1 0 )
ok : ( f 1 ——> 1 1 1 1 1 1 0 1 )
ok : ( f 2 ——> 1 1 1 1 1 0 1 1 )
ok : ( f 3 ——> 1 1 1 1 0 1 1 1 )
ok : ( f 4 ——> 1 1 1 0 1 1 1 1 )
ok : ( f 5 ——> 1 1 0 1 1 1 1 1 )
ok : ( f 6 ——> 1 0 1 1 1 1 1 1 )
ok : ( f 7 ——> 0 1 1 1 1 1 1 1 )
ok : ( f 8 ——> 1 0 1 1 1 1 1 1 )
ok : ( f 9 ——> 1 1 0 1 1 1 1 1 )
ok : ( f a ——> 1 1 1 0 1 1 1 1 )
ok : ( f b ——> 1 1 1 1 0 1 1 1 )
ok : ( f c ——> 1 1 1 1 1 0 1 1 )
ok : ( f d ——> 1 1 1 1 1 1 0 1 )
ok : ( f e ——> 1 1 1 1 1 1 1 0 )
ok : ( f f ——> 1 1 1 1 1 1 1 1 )
ok : ( 0 f ——> 0 1 1 1 1 1 1 1 )
ok : ( 1 f ——> 1 0 1 1 1 1 1 1 )
ok : ( 2 f ——> 1 1 0 1 1 1 1 1 )
ok : ( 3 f ——> 1 1 1 0 1 1 1 1 )
ok : ( 4 f ——> 1 1 1 1 0 1 1 1 )
ok : ( 5 f ——> 1 1 1 1 1 0 1 1 )
ok : ( 6 f ——> 1 1 1 1 1 1 0 1 )
ok : ( 7 f ——> 1 1 1 1 1 1 1 0 )
ok : ( 8 f ——> 1 1 1 1 1 1 0 1 )
ok : ( 9 f ——> 1 1 1 1 1 0 1 1 )
ok : ( a f ——> 1 1 1 1 0 1 1 1 )
ok : ( b f ——> 1 1 1 0 1 1 1 1 )
ok : ( c f ——> 1 1 0 1 1 1 1 1 )
ok : ( d f ——> 1 0 1 1 1 1 1 1 )
ok : ( e f ——> 0 1 1 1 1 1 1 1 )
ok : ( f f ——> 1 1 1 1 1 1 1 1 )
PRESS TEST BUTTON TO EXIT
