18 - 2 COMPOSITION OF GAME BOARD
Ensure that the DIP SW setting is performed as designated. Failure to observe this
may cause functioning not suitable for the actual operation, or malfunctioning.
DIP SW
FIG. 18. 2 b
FIG. 18. 2 a
ROM CASE NAO WRG
840-0064C
ASSY CASE NAO
COMMUNICATION BD
840-0001E
SCREW (4)
M3 X 50,chrome plated
In this product, set all of the DIP Switches to OFF.
DIP SW SETTING
ASSY CASE NAOMI MAIN BD USA:840-0001A-06
ASSY CASE NAO WRG USA (840-0064D-06) : USA
STOP
IMPORTANT!
To Next Page
