Sega WaveRunner GP - Page 72

64
www.seuservice.com
www.seuservice.com
65
17
1514
13
12
11
5
6
7
8
9
10
4
3
2
1
21
20
19
18
Item # Part# Description Notes
1 999-1861 Start Button
2 999-1880 Handle Cover
3 999-1862 View Button
4 999-1881 Handle Bar Bracket
5 999-1882 Handle Bar
6 999-1883 Handle Grips
7 999-1884 Handle Shaft Bearing
9 999-1885 Handle Shaft
10 999-1886 Handle Stopper
11 999-1887 Handle Assembly Body
12 998-0196 Accel Harness
13 999-1889 Accel Pot Bracket
14 999-1892 Accel Pot Gear
15 999-1896 Accel Pot
16 999-1898 Accel Lever
17 999-1890 Accel Lever Bracket
18 999-1895 Accel Spring
19 999-1891 Steering Pot Bracket
20 999-1888 Handle Assembly Body Lower
21 999-1893 Handle Shaft Gear
22 999-1897 Steering Pot
23 999-1894 Steering Pot Gear
16
2322
24
