AIR FILTER
The air filter element is a paper air filter type. Air filter needs to
be cleaned or replaced after a period of use, as described in the
periodic maintenance table.
First remove the filter element to check. If air filter element is
soaked with
oil or serious dust,
air filter element
should not be
cleaned, but directly replaced with a new air filter element.
If there is no oil immersion or serious dust, clean the air filter
intake side down and lightly knock on the ground. Most of the
dust will fall off after tapping. If you have air pump, you can use
compressed air from the filter inner side to blow out (not from the
intake side), to blow the dust off to clean the air filter.
Removing
the
air
filter
cover
1
Air filter cover
2
Air box cover clamp
3
Air filter element
4
Air filter plug
The air filter element is located under the air filter cover in front of
the seat. Replacement steps are as follows:
