Improper adjustment of the handlebars or improper tightening bolts
can result in loose handlebars and lost of steering. Loss of control can
result in severe injury or death. Always follow the adjustment
procedure, or check out the services at your dealer.
HANDLEBARS ADJUSTMENT
The handlebars can be adjusted to suit the rider's preferred position.
1
M8×45 (4x)
Torque to specifications.
1.
Loosen the four handlebar bolts.
2.
Adjust the position of the handlebars according to the rider
needs.
3.
Tighten the two front bolts and then tighten the two rear bolts.
Leave a gap of 3 mm at the back of the clamp block.
4.
Tighten the fastening bolts to specifications.
