21
22
9.
Specifications
Product Name Segway eScooter E110SE
Segway eScooter E110S
Segway eScooter E125S
Dashboard
Digital
Digital & VA panel
Digital & VA panel
Digital & VA panel
Power Indicator
10-Segment display
10-Segment display
10-Segment display
Smart
features
AirLock
Yes
Yes
Yes
Handlebar Lock
Yes
Yes
Yes
Seat Trunk Lock
Yes
Yes
Yes
Seat Detection
Yes
Yes
Yes
Kickstand Detection
Yes
Yes
Yes
OTA
Yes
Yes
Yes
AHRS
Yes
Yes
Yes
Built-in IoT
Yes
Yes
Yes
Cruise mode
Yes
Yes
Yes
Smart BMS 6.0
Yes
Yes
Yes
*WMTC criteria: 75kg load
±
5kg, 1.75m
±
0.05m, max wind speed of 3m/s with a minimum air temperature of 5ºC and a maximum of 35ºC.
*Typical range: The accumulated range of the vehicle (25 km/h or 45 km/h version) tested at their respective maximum speed with 165 lbs
(75 kg), 77 °F (25 °C), wind speed
3m/s on a paved road until no more power remains.
*Some of the factors that affect range include: rider weight, number of starts and stops, ambient temperature, etc.
e.g. (E110SE) maximum achievable range of about 91 km at a constant speed of 20 km/h with 75 kg load in about 25 °C temperature on a
flat asphalt surface, maximum achievable range of about 84 km at a constant speed of 20 km/h with 90 kg load in about 20 °C temperature
on a flat asphalt surface.
e.g. (E110S) maximum achievable range of about 80 km at a constant speed of 20 km/h with 75 kg load in about 25 °C temperature on a flat
asphalt surface, maximum achievable range of about 72 km at a constant speed of 20 km/h with 90 kg load in about 20 °C temperature on
a flat asphalt surface.
e.g. (E125S) maximum achievable range of about 130 km at a constant speed of 20 km/h with 75 kg load in about 25 °C temperature on a
flat asphalt surface, maximum achievable range of about 111 km at a constant speed of 20 km/h with 90 kg load in about 20 °C temperature
on a flat asphalt surface.
Product Name
Segway eScooter E110SE
Segway eScooter E110S
Segway eScooter E125S
Vehicle
Parameters
Dimensions (W×H)
1876 × 675 × 1169 mm
1876 × 675 × 1169 mm
1856 × 675 × 1169 mm
Vehicle Weight
(batteries not included)
78 kg
78 kg
90 kg
Wheelbase
1365 mm
1365 mm
1365 mm
Max. Speed
25 km/h
45 km/h
25 km/h
45 km/h
25 km/h
45 km/h
Electric Range(WMTC Stage3)*
59 km
49 km
47 km
40 km
102 km
81 km
Typical range*
84 km
65 km
73 km
57 km
123 km
108 km
Energy Consumption
30 Wh/km
37 Wh/km
28 Wh/km
37 Wh/km
28 Wh/km
39 Wh/km
Max. Motor Output Power
1.5 kW
1.5 kW
3 kW
Max. Torque for Drive Wheel
88 N·m
88 N·m
120 N·m
IP Rating
IPX5
IPX5
IPX5
Space under Seat
27 L
27 L
27 L
Seats
For two persons
For two persons
For two persons
Battery
Battery Type
Li-ion
Li-ion
Li-ion
Charging Time
56 hours
45 hours
4 hours
IP Rating
IPX7
IPX7
IPX7
Capacity
38 Ah
30 Ah
30 Ah × 2
Weight
11 kg
11 kg
11 kg × 2
Rated Voltage
48 V
48 V
48 V
Battery Energy
1824 Wh
1440 Wh
2880 Wh
Charger
Nominal Power
420 W
420 W
1120 W
Charger Input Voltage
200240V~ 50Hz 3.0A MAX
200240V~ 50Hz 3.0A MAX
200240V~ 50/60Hz 6.5A MAX
Charger Output Voltage
52.5 V
52.5 V
54.2 V
Tyre
Tyre Type
Front: 80/90-12, tubeless tyre
Front: 80/90-12, tubeless tyre
Front: 100/70-12, tubeless tyre
Rear: 90/80-12, tubeless tyre
Rear: 90/80-12, tubeless tyre
Rear: 120/70-12, tubeless tyre
Standard Tire Pressure
Front: 200 kPa
Front: 200 kPa
Front: 200 kPa
Rear: 220 kPa
Rear: 220 kPa
Rear: 220 kPa
Brakes
Front brake
Disc
Disc
Disc
Rear brake
Disc
Disc
Disc
