Quick Installation Guide [en] 3
Technical Data
Properties Values
Network connector
logical:
physical:
IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT)
1 × RJ-45 (STP, category 5 or better)
Device connection • 2 × USB 3.0 SuperSpeed (USB ports 1–2)
Current input • approx. 500 mA at 5 V direct current without load
• approx. 2500 mA at 5 V direct current with full
load on the USB ports
Power consumption • approx. 3 W without load
• approx. 14 W with full load on the USB ports
• approx. 26–123 kWh/year, depending on
utilization
Operating environment ambient temperature: 5–40 °C
relative humidity: 20–80 %
Dimensions width: 120 mm
height: 30 mm
depth: 84 mm
weight: 125 g (without power supply unit)
USB ports 1-2
with LED for the USB port
2
1
network connector
(RJ-45)
(at the rear side)
power supply
connector
(at the rear side)
status LED
(RGB)
activity LED
(yellow)
link LED
(green)
