Seko MSA Series - Page 7

SPR0136037 Rev. 1.5
2
Table 2

PVDF pump head(with DN15 connector( number 10 and 11)

additional cost will be
charged)
Number
Description
Quantity
1
Pump head
1
2
Seal D18,72X2,62
2
3
Seal14,48X2,69
2
4
Ball seat
2
5
Seal7,65X1,78
2
6
Ball
2
7
Ball cage
2
8
Valve body
2
9
Seal 12,37 X T 2,62
2
10
Gasket
2
11
Connecting nut PVDF
2
12
Gasket for M6 screw
8
13
Spring pad for M6 screw
8
14
M6x25 Hexagon screw
8
15
Cover for pump head
1
Table 3

SS316L pump head
Number
Description
Quantity
1
Pump head
1
2
Ball
2
3
Ball cage
2
4
Ball seat
2
5
Valve body
2
6
Seal D12,42XT1,78
2
7
Seal D18,72X2,62
2
8
Valve cap
2
9
Washer for M6
8
10
Spring washer for M6
8
11
Screw M6x50
8
