8.1 Cutting specifications
In plasma cutting, the thickness of the material to be cut, the
speed of cutting and the current supplied by the generator have
values which are related to each other; these depend on the
type and quality of the material, type of torch as well as the type
and condition of the electrode and nozzle, distance between
nozzle and piece, pressure and impurity of the compressed air,
cut quality required, temperature of the piece to be cut, etc.
In the diagrams as in Fig. 1, 2, 3, 4, 5 we can see that the thick-
ness to be cut is inversely proportional to the cutting speed,
and that both these values can be increased with an increase
in current.
GENESIS 60
Fig. 1
Fig. 2
MILD STEEL
Thickness (mm)
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
8
10
15
1
2
3
4
8
10
15
20
Current (A)
20
20
20
20
30
30
30
30
40
40
40
40
50
50
50
50
50
50
50
60
60
60
60
60
60
60
60
Speed (mm/min)
1500
600
400
300
3000
1200
750
500
5000*
2000
1700
1200
7800
3700*
2500*
1800
700
600
250
10500
6000
3000
2500*
1000*
800*
400*
200
STAINLESS STEEL
Thickness (mm)
1
2
1
2
3
1
2
3
4
6
8
10
15
1
2
3
4
6
8
10
15
20
Current (A)
30
30
40
40
40
50
50
50
50
50
50
50
50
60
60
60
60
60
60
60
60
60
Speed (mm/min)
1700
700
3000*
1400
1000
6400
2400*
1500
1200
850
700
450
250
10500
6000
3000*
1700*
1200*
900*
750*
350
200
ALUMINIUM
Thickness (mm)
1
1
2
3
1
2
3
4
1
2
3
4
6
8
10
1
2
3
4
6
8
10
15
Current (A)
20
30
30
30
40
40
40
40
50
50
50
50
50
50
50
60
60
60
60
60
60
60
60
Speed (mm/min)
2400
4000*
1500
1200
6700*
3200*
2200
1100
10100
5000*
3000*
2000
1200
950
700
14000
10000
4800
3000*
1900*
1600*
1400*
600
* High quality cut
