Selden 22 - Parts Included

6
2.1 Parts included in side console package, art. no. 442-200-10
Side bracket
Item Art. No. Quantity Description
(all measurments in mm)
1 442-200 2 BRACKET 102x52x39
2 442-202 2 WASHER Ø21x7
3 153-006 2 SCREW MC6S M8x20
4 442-203 2 COVER 88x33x13.5
5 153-178 8 SCREW MLC6S M4x8
Joint bracket
1 442-201 2 JOINT BRACKET 79.5x60x40
2 442-205 2 END STOP 42.5x20x17
3 153-178 4 SCREW MLC6S M4x8
4 442-210 4 WASHER PLATE ST-22
5 153-001 4 SCREW MC6S 6x20
- 312-305 2 LOCKING ADHESIVE 1ML
Leg
1 442-204 4 LEG Ø25x500
2 151-120 4 THREAD BAR M8x500
3 164-401 4 WASHER Ø16/8-1.5 (M8)
4 158-006 4 NYLOC NUT M8
- 157-004 8 FULL NUT M8
- 312-305 1 LOCKING ADHESIVE 1ML
Centre console
1 442-209 2 CENTRE CONSOLE 80x51x46
2 151-105 4 SCREW M6x16
3 164-407 4 WASHER Ø12/6-6 (M6)
4 157-003 4 NUT M6M
5 442-211 2 NUT HOLDER
