16
Apply silicone around and on the top of screws
21
Tidy silicon
Connect the cable to the ANT port on the
controller
Remove masking tape
23
24
22
+
+
-
26
Get power input cable for battery connection
25
Match the power cables polarities to the battery
polarities, red to red / black to black
2827
Plug the other end of power input cable to the
controller
Place the controller at where user wants with
using M4x25 screws
