SemaConnect 4 EV Series - Table of Contents

1
TABLE OF CONTENTS
1. Safety and Compliance 2
2. Electrical Requirements 3
3. Parts List 4
4. Installation 4
5. Conguration 8
6. Operation 10
7. Troubleshooting and Maintenance 12
WARNINGS
Please read the full document before using this SemaConnect charger. While working
with electrical devices please follow basic electrical safety procedures.
Do not try to install this charger while the breaker is still powered on.
Do not try to install this charger near ammable or explosive materials.
Do not try to operate this charger if there are any signs of physical damage, i.e., cracks,
corrosion, or exposed wiring.
Do not try to modify this charger in any way not listed in this guide.
Do not try to resolve any issues with the charger that have not been outlined in the
troubleshooting section of this guide.
Do not allow an unlicensed individual to wire this charger during the installation process.
Do not insert any nger or any other foreign object into the connector of this charger.
If the user of this device has any medically implanted device, please contact the medical
device manufacturer to discuss how charging may affect the medical device before
attempting to use this charger.
Follow all instructions in this guide during the installation of this device to avoid
any additional complications.
