5. Conguration
Powering Up the Charger
After you have installed the SemaConnect Series 4 EV Home Charger, turn on the power at the breaker.
Allow up to 3 minutes for the charger to fully power on. The charger is ready to use when the LED is a steady blue
color and icons are visible on the screen. If the charger does not power on, contact your electrician to ensure
correct electrical installation.
The charger may now be connected to a vehicle to start charging. Please note the following default settings, which
may be changed by conguring the charger.
• Power level is set to 16 amps
• Unlocked
• No schedule
Appropriate Amperage Setting
The charger may be congured to charge a range of amperage levels. It is essential not to select a level that is
greater than your circuit breaker is rated for. Other factors, such as the electrical capacity of your panel and wiring
size, may need to be considered. Please consult with a qualied electrician if in doubt.
The tables below provide guidance on the amperage level to congure on the charger based on the circuit rating.
CIRCUIT RATING NEMA INSTALLATION HARDWIRED INSTALLATION
70 A N/A 50 A
60 A N/A 48 A
50 A 40 A 40 A
40 A 32 A 32 A
30 A 24 A 24 A
20 A 16 A 16 A
Conguring the Charger
The charger may be congured to provide the optimal power level and, optionally, connect the charger to your
home WiFi network. Connecting the charger to WiFi will enable additional features and is recommended if WiFi
is available at the installed location.
Connecting to the SemaConnect Mobile App
• Download the SemaConnect mobile application to your smartphone.
• Open the app, click on My Account, and log in (create an account if you do not have one).
Note: The SemaConnect mobile app provides access to all public SemaConnect charging stations in
addition to the Series 4 EV Home Charger.
Apple App Store
Google Play Store
