A. Base Unit
Installation
Please set up the base unit according to
the following steps (1)~(8).
(1) Install the telescopic antenna of the
base unit and extend it fully and
vertically.
(5) Set the dialling mode to
TONE. If you can not dial,
set it to PULSE.
(8) Plug the AC adaptor
into power outlet.
(6) Please use only the SENAO
AC adaptor supplied with
the base unit, and connect the
AC adaptor to the DC IN jack.
(4) Connect the telephone line
to the LINE jack with the
local telephone system.
(3) During installation, pick up the hand
held of the standard telephone to avoid
electric shock caused by an incoming call.
(2) Connect the standard telephone to
the TEL. jack.
(7) The AC adaptor is
set on 220V. If your
power source is 110V,
please switch it to
110V before installing.
(7)
220V110V
AC adaptor
(Output DC 12V )
(3)
(8)
(6)
(1)
(5)
(4)
(2)
8-EN
