Connecting devices to the Soundbar
AMBEO Soundbar | Max | 27
Connecting a subwoofer (optional)
Optionally, you can connect a subwoofer to the Soundbar.
▷ Recommended settings: Adjust the volume on the subwoofer to
“approx. 50%” and set the crossover to “Max”.
▷ Connect one connector of the mono RCA cable (to be ordered
separately) to the SW PRE OUT
socket on the Soundbar.
▷ Connect the other connector of the cable to the socket LOW
LEVEL IN/MONO of the subwoofer.
▷ Calibrate the Soundbar (> 31).
Disconnecting the subwoofer
When the subwoofer is disconnected from the Soundbar, the Sound-
bar uses the previous calibration without subwoofer, if one exists.
The app allows you to choose between the calibration with and with-
out subwoofer.
AUX IN
SW PRE
OUT
OPT IN
HDMI 3 IN
HDMI 2 IN
HDMI 1 IN
HDMI TV
(eARC) OUT
ETHERNET
USB
POWER
LOW LEVEL
IN/MONO
2
1
3
Volume: 50 %
Crossover: Max
