EW-D ASA antenna splitter
205
3 4 BNC sockets B1 to B4
• RF outputs of diversity branch B for connection to the re-
ceiver
• See „Connecting receivers to the EW-D ASA“
4 ANT RF IN B BNC socket
• Antenna input of diversity branch B
• See „Connecting antennas“
5 ANT RF IN A BNC socket
• Antenna input of diversity branch A
• See „Connecting antennas“
6 4 BNC sockets A1 to A4
• RF outputs of diversity branch A for connection to the re-
ceiver
• Each one of these RF outputs can also provide power to
an EW-D EM receiver
• See „Connecting receivers to the EW-D ASA“
7 RF OUT A BNC socket
• RF output only for connecting an additional ASA 214 to
build an 8-channel diversity system
• See „Configuring multi-channel systems“
8 DC in socket
• To connect the NT 12-35 CS power supply unit
• See „Connecting/disconnecting the EW-D ASA to/from
the power supply system“
9 Strain relief for the connection cable of the power supply
unit
• See „Connecting/disconnecting the EW-D ASA to/from
the power supply system“
Connecting/disconnecting the EW-D ASA
to/from the power supply system
To supply power to the EW-D ASA, the connected receivers
(EW-D EM only) and any antenna amplifiers used, you will
need the NT 12-35 CS power supply unit.
Use only the supplied NT 12-35 CS power supply unit. It is de-
signed for your antenna splitter and ensures safe operation.
To connect the EW-D ASA antenna splitter to the power sup-
ply system:
