The Building Blocks of a Wireless System
Every wireless system consists of three main components:
1) Transmitter
The transmitter accepts a (mic or line) input signal, converts it into an RF
(radio frequency) signal, and then transmits it.
2) Receiver
The receiver picks up the transmitted RF signal, converts it back into an audio signal,
and then outputs it for mixing and amplification.
3) Antennas
Antennas handle the sending and receiving of the RF signal between the two components.
Antennas may be either active or passive, depending on the system configuration.
A1031-U
Passive Omnidirectional
UHF Antenna
A2003-UHF
Passive Directional
UHF Antenna
G3 EM Rack-Mount Receiver G3 EK Camera-Mount Receiver
G3 SKM Handheld Transmitter G3 SKP Plug-On Transmitter G3 SK Bodypack Transmitter
