SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10024
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 500846 CABLE -V-CP RF NHA
010 515066 . HOUSING 125X34X0.08 1
020 515032 . COVER 1
030 514162 . SLIDE KNOB 2
040 515098 . INSERT ROUND 5,6X4 1
050 549394 . OPTICAL WAVEGUIDE, 10 PCS. 1
060 522096 . CROSS SCREW 2.2X5 4
070 525759 . PCB ASSEMBLY FOR CABLE -V-CP 1
080 514166 . KNOB 10.5X3.4 1
090 514164 . KNOB 10.5X3.7 1
100 514170 . INSERT ROUND 6.3X3.8 1
110 549392 . INSERT ROUND 5.2X2.7, 10 PCS. 1
120 549391 . INSERT BLACK, 10 PCS. 2
130 538741 . CABLE COPPER 1.54M
(SEE FIG. 17 FOR DET.)
1
140 538747 . CABLE COPPER 0.33M 1
-150 528106 . LABEL 1
ZZ160 515830 . FOLDER BOX, 150X40X170 1
ZZ170 085161 . LABEL, 89X97.6 1
- ITEM NOT ILLUSTRATED
