Sennheiser HMEC 26 - Inspection; Check; General 5001; Visual Inspection of the Headset

SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 5001
Feb 10/10
23-41-48
INSPECTION / CHECK
1. General
NOTE: The procedure that follows is applicable to all variants of the Headset HMEC 26-Series.
2. Visual inspection of the Headset
A. Visual inspection of the headset
(1) Do a visual check of the headset for structural damages and damaged cables.
NOTE:
FOR THE SOLDERING OF LOOSE LEADS, REFER TO REPAIR.
B. Visual inspection of the headband and the earpads
NOTE:
REFER TO IPL FIG. 1 AND IPL FIG. 3.
(1) Do a visual check of the headband (010) and the earpads (100) for damages or contaminations.
NOTE:
ALWAYS REPLACE THE LEFT AND THE RIGHT EARPADS. FOR HYGIENIC REASONS REPLACE
THE TWO EARPADS FROM TIME TO TIME.
Feb 10/10I
nspection /
Check
