SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10028
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 502437 CABLE -V-KX RF NHA
010 515066 . HOUSING 125X34X0.08 1
020 515455 . COVER 1
030 514162 . SLIDE KNOB 2
040 549394 . OPTICAL WAVEGUIDE, 10 PCS. 1
050 522096 . CROSS SCREW 2.2X5 4
060 528105 . PCB ASSEMBLY FOR CABLE -V-KX 1
070 514166 . KNOB 10.5X3.4 1
080 514164 . KNOB 10.5X3.7 2
090 514170 . INSERT ROUND 6.3X3.8 1
100 549392 . INSERT ROUND 5.2X2.7, 10 PCS. 1
120 538741 . CABLE COPPER 1.54M
(SEE FIG. 17 FOR DET.)
1
130 538750 . CABLE COPPER, 0.33M
WITHOUT PLUG (XLR-3)
1
140 538737 . CABLE COPPER 0.33M
6.3MM JACK PLUG
1
150 538738 . CABLE COPPER 0.33M
5.25MM JACK PLUG
1
-160 528106 . LABEL 1
ZZ170 515830 . FOLDER BOX, 150X40X170 1
ZZ180 085161 . LABEL, 89X97.6 1
- ITEM NOT ILLUSTRATED
Oct 30/08
