Sennheiser HMEC 26 - Page 108

SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10032
Mar 13/13
23-41-48
- ITEM NOT ILLUSTRATED
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 500838 CABLE -BV-CP RF NHA
010 600650 . BATTERY HOUSING 1
020 515032 . COVER 1
030 549394 . OPTICAL WAVEGUIDE, 10 PCS. 1
040 514162 . SLIDE KNOB 1
050 545278 . SCREW M2X8 TORX 4
060 525757 . PCB ASSEMBLY FOR CABLE -BV-CP
WITH INSULATING FOIL
THE INSULATING FOIL (PART NO.
600666) IS PART OF THIS PCB ASSY
1
070 514164 . KNOB 10.5X3.7 1
080 514166 . KNOB 10.5X3.4 1
090 514170 . INSERT ROUND 6.3X3.8 1
100 549392 . INSERT ROUND 5.2X2.7, 10 PCS. 1
110 549391 . INSERT BLACK, 10 PCS. 1
120 515098 . INSERT ROUND 5,6X4 1
130 538741 . CABLE COPPER 1.54M
(SEE FIG. 17 FOR DET.)
1
140 538747 . CABLE COPPER 0.33M XLR-5 1
-150 528106 . LABEL 1
-160 545755 . CLIP BELT-ASA-BK, PACKED 1
ZZ170 515830 . FOLDER BOX, 150X40X170 1
ZZ180 085161 . LABEL, 89X97.6 1
Feb 10/10
Jan 10/09
