SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10034
Mar 13/13
23-41-48
- ITEM NOT ILLUSTRATED
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 502183 CABLE -B-K RF NHA
010 600650 . BATTERY HOUSING 1
020 515033 . COVER 1
030 549394 . OPTICAL WAVEGUIDE, 10 PCS. 1
040 545278 . SCREW M2X8 TORX 4
050 525761 . PCB ASSEMBLY FOR CABLE -B-K
WITH INSULATING FOIL
THE INSULATING FOIL (PART NO.
600666) IS PART OF THIS PCB ASSY
1
060 514164 . KNOB 10.5X3.7 1
070 514170 . INSERT ROUND 6.3X3.8 1
080 549392 . INSERT ROUND 5.2X2.7, 10 PCS. 1
90 549391 . INSERT BLACK, 10 PCS. 1
100 538741 . CABLE COPPER 1.54M
(SEE FIG. 17 FOR DET.)
1
110 538737 . CABLE COPPER 0.33M
6.3MM JACK PLUG
1
120 538738 . CABLE COPPER 0.33M
5.25 MM JACK PLUG
1
-130 528106 . LABEL 1
-140 545755 . CLIP BELT-ASA-BK, PACKED 1
ZZ150 515830 . FOLDER BOX, 150X40X170 1
ZZ160 085161 . LABEL, 89X97.6 1
Oct 30/08
