SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 9001
Jan 10/09
23-41-48
SPECIAL TOOLS, FIXTURES, EQUIPMENT AND CONSUMABLES
1. Test tools and equipment
2. Consumables
GTE NO. DESCRIPTION SPECIFICATION/TYPE SOURCE
1 Power supply U: 0-30V DC adjustable
I: ≥500 mA
eff
Hum: <1%
Commercial
2 Sine wave generator AF Level adjustable to
775 mV
eff
at 1 kHz
Commercial
3 Multimeter U: 0-30V DC
I: ≥500 mA
eff
Resolution ≤ 0.1 V
Commercial
4 Oscilloscope - Commercial
5 Intercom/ Audio system - Commercial
Table 9001
Test tools and equipment
MATERIAL SOURCE
Lintfree cloth Commercial
Mild soapy water Commercial
Table 9002
Consumables
Jan 10/09
Special
Tools, Fix-
tures,
Equip-
ment and
