SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10011
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 502404 HEADSET HMEC 26-T, WITHOUT CABLE RF
010 552768 . HEADBAND WITH HEADBAND PADDINGS
(SEE FIG. 18 FOR DET.)
1
020 531421 . LABEL FOR THE HEADSET 1
030 525227 . CLIP FOR THE CAP, NON MICROPHONE SIDE 1
040 600754 . CAP
NON MICROPHONE SIDE
1
045 600735 . ROCKER BUTTON 1
046 522460 . OPTICAL WAVEGUIDE 1
050 538260 . ACOUSTIC UNIT, ACTIVE, TALK THROUGH,
NON MICROPHONE SIDE
THE ACOUSTIC UNIT HAS BEEN REDESIGNED.
UP TO HEADSETS SERIAL NUMBER
00200100 ALWAYS REPLACE THE LEFT AND
THE RIGHT ACOUSTIC UNIT AND THE LEFT
AND RIGHT EARPAD (REF FIG. ITEM 100)
FROM HEADSETS SERIAL NUMBER
00200100 REPLACE THE DEFECTIVE
ACOUSTIC UNIT ONLY !
1
060 538261 . ACOUSTIC UNIT, ACTIVE, TALK THROUGH,
MICROPHONE SIDE
THE ACOUSTIC UNIT HAS BEEN REDESIGNED.
UP TO HEADSETS SERIAL NUMBER
00200100 ALWAYS REPLACE THE LEFT AND
THE RIGHT ACOUSTIC UNIT AND THE LEFT
AND RIGHT EARPAD (REF FIG. ITEM 100)
FROM HEADSETS SERIAL NUMBER
00200100 REPLACE THE DEFECTIVE
ACOUSTIC UNIT ONLY !!
1
070 531424 . CAP WITH MICROPHONE ARM SUPPORT,
CABLE AND CLIP, MICROPHONE SIDE
(UP TO SERIAL NO. 00200100)
1
-070 540367 . CAP WITH MICROPHONE ARM SUPPORT,
CABLE AND CLIP, MICROPHONE SIDE
(FROM SERIAL NO. 00200100)
1
080 550245 . MICROPHONE ARM, BKE 46-80
(FROM SERIAL NO. 00200100)
1
- ITEM NOT ILLUSTRATED
